Martindale abrasion tester Updated
| Parameter | Details |
|---|
| Workplace | 9 places |
| Counting Range | 0 – 999999 times |
| Maximum Travel | 60.5 ± 0.5 mm and 24 ± 0.5 mm |
| Pressure Mass |
| – Clothing Sample Hammer | 397 ± 2 g |
| – Furniture Decoration Sample Hammer | 597 ± 2 g |
| – Stainless Steel Discs | 260 ± 1 g |
| Effective Friction Diameter of Grinding Block |
| – Type A (198g, 3 kPa) | Friction head: 28.8 – 0.084 mm |
| – Type B (155g, 1.52N) | Friction head: 90 – 0.10 mm |
| Relative Velocity (Gripper vs Grinding Table) | 50 ± 2R / min (adjustable from 20–70 rpm) |
| Sampling Hammer Quality | 2385 ± 10 g |
| Machine Size | 870 × 580 × 300 mm |
| Power Supply | AC220V, 50Hz, 500W |
| Machine Weight | 73 kg |
Xenon Arc Test Chamber YG(B) 611-3C
| Feature | Details |
|---|---|
| Xenon Arc Lamps | Uses 1500W long Xenon arc lamp to simulate sunlight (IR, visible, UV); supports band switching per test standards; energy-efficient and accurate. |
| Temperature Monitoring | Supports BST (Black Standard Thermometer) and BPT (Black Panel Thermometer) for complete surface and internal temperature monitoring. |
| Temperature Control | Built-in air filtration and circulation system; maintains 20–50℃ with ±2℃ accuracy. |
| Performance | Powerful CPU with real-time display of results, charts, and curves for precise test control. |
| Sample Capacity | Tests up to 13 samples (GB standard) or 6 samples (ASTM); sample holder rotates at 5 RPM for consistent exposure. |
| Built-in Printer (Optional) | Optional thermal printer for immediate result output. |
| Standard Compatibility | Complies with ISO, GB/T, TM, AATCC standards. |
| User Interface | 7-inch touchscreen with animations and digital charts for intuitive and clear operation. |
